Box semi trailers are mainly used in the bulk cargo transportation like precision parts, logistics express delivery,food goods and other kinds cargo,it is a common type of semi-trailer used in freight transport. Van Semi trailer is designed primarily for hauling goods that need to be protected from the elements.
Box semi trailers are versatile and essential for transporting bulk cargo efficiently. With a rated capacity ranging from 30 to 100 tons, they can accommodate a wide variety of loads. The dimensions, which vary from 7000mm to 18000mm, provide flexibility in terms of the volume of cargo they can carry.
Customization options for these trailers enhance their functionality and adaptability to specific needs. You can choose the side wall height, which can be crucial for securing different types of cargo. Additionally, the number and type of side or back doors, along with their opening mechanisms, can be tailored to improve loading and unloading efficiency. These features ensure that the trailer meets your specific operational requirements, making it a valuable asset in logistics and transportation.
The structure of box semi trailers
Cargo Box Semi Trailer frame including main bream,cross bream,side bream,other reinforced plate and so on,adopt high strength corrugated steel plate to make sure the bearing capacity.
The box is enclosed, rectangular part of the box trailer, designed to protect the cargo.normally use high strength corrugated steel sheet.
The doors at the rear end of the box semi trailer,are typically roll-up or swing doors, providing access to the cargo compartment.
Dry Box Semi Trailer braking System have air brakes connected to the tractor’s braking system for safe stopping.
Technical Specification
Semi Trailer Type | Box Semi Trailer |
Axles | 2 /3 Axles*13Ton,FUWA/BPW or Customization |
Loading Capacity | 20-60 Tons |
Box Semi Trailer size | 13,000x2,500x4,000mm(Customization) |
Material | Q345B,Beam Height:500mm,Upper Plate:14mm ,Bottom Plate:16mm,Middle:8mm |
Bottom Plate Thickness | 3mm |
Box Body | Corrugated Steel sheet 2mm |
King Pin | 50#(2")/90#(3.5") JOST/Other Brand |
Braking System | Air Dual braking system,with relay valve |
Suspension | Reinforced mechanical Suspension,90mm*13mm*10 layers |
Landing gear | 28 Tons Two Speed,JOST/Other Brand |
Tire | 12R22.5 (8/12 Pieces) Linglong/Triangle/Double-Coin/Bridgestone/Other |
Enclosed Van Semi Trailer Features
Box trailer adopts high strength steel and best design to ensure the semi trailer with high strength and lightweight design.providing a good balance between structural integrity and weight.
Trailer box body adopt corrugated steel plate with more strength and Durability.
The braking system of a box semi-trailer is a critical safety feature, designed to slow down or stop the trailer when necessary.
Dry Van Semi Trailer use Heavy-duty landing gear,reinforced landing gear systems designed to handle significantly greater weight and stress.
